Toyota Camry battery size

Battery group size

H5 / H6

Depends on engine / version

2024 Toyota Camry · 3 versions: see the table below

585–605 CCA min, by version Type not specified: match your current battery

All verified years: Group 24F (2007–2017) · Group H6 (48) (2018–2024) · Group H5 (47) (2018–2024)

– = not specified in our sources (hover for details): match the CCA or type on the battery in your car now. Last verified 2026-10-19; sources are listed below.

Check your car first

• 2020–2024 2.5L 4-cyl (gas): 2024 is confirmed by Toyota's guide only.
• 2018–2024 2.5L Hybrid, 12V auxiliary battery: On the hybrid the 12V battery sits in the trunk and is vented outside. Sources list different CCA ratings by option package, so we don't show one; match the label on your battery.
• 2018–2024 3.5L V6: 2024 is confirmed by Toyota's guide only (Interstate's guide ends at 2023).
• 2010–2017 2.5L 4-cyl (gas): Toyota also lists Group 35 as an option for 2010-2011.
• 2007–2017 3.5L V6: Toyota also lists Group 35 as an option for 2007-2011.
• Not shown yet: 2000-2006 (size depends on US vs. cold-climate build; sources split between 24F and 35), 2007-2009 2.4L (sources disagree), 2007-2017 hybrids (Japanese JIS sizes; Toyota says use the original battery's spec), 2025+ (new generation, not yet verified).

Confirm in your owner's manual. Battery fitment can change with engine, trim, option packages, market (US vs. Canada) and mid-year production changes. Before you buy, check the label on the battery that's in your car now and your owner's manual.

Sources for each row

Full source list: Toyota TrueStart Batteries, 2025-2026 Updates (application guide) (checked 2026-10-19) · Interstate Batteries Application Guide 2023 (2000-2023 model years) (checked 2026-10-21) · 2021 Mopar Batteries Application Guide (BCI replacement data) (checked 2026-10-21). We store facts and links only; we don't copy manuals or guides. How we check specs.

How to replace the battery

Tools: 10 mm wrench or socket (some hold-downs need 12 or 13 mm or an extension), gloves, eye protection, terminal brush. Time: about 15–30 minutes for an under-hood battery; longer if it's in the trunk or under a seat.

1. Park, turn everything off and take the key or fob out of the car.
2. Disconnect the negative (–) cable first, then the positive (+).
3. Remove the hold-down and lift the battery out. Batteries are heavy (often 35–60 lb); lift with your legs.
4. Clean the tray and cable ends. Set in the new battery with the posts on the same sides as the old one.
5. Fit the hold-down, connect positive (+) first, then negative (–). Tighten until the clamps don't twist by hand.
6. If your car has a vent tube on the battery (common for trunk or cabin batteries), reconnect it.
7. Start the car. Some newer vehicles with a battery monitor need a reset or registration after a new battery. Your owner's manual explains it; a parts store or dealer can do it if needed.

Most parts stores take old batteries for recycling and usually refund a core charge.

Recalls for the Toyota Camry (2007–2024)

NHTSA lists 38 recall campaigns across the years shown on this page (all components, not just batteries). Check your own car by VIN at nhtsa.gov/recalls.

Most recent 6 shown. Source: NHTSA Recalls API (recallsByVehicle), snapshot 2026-10-21.

FAQ

What size battery does a Toyota Camry take?

Verified sizes by year: Group 24F (2007–2017), Group H6 (48) (2018–2024), Group H5 (47) (2018–2024). The exact size depends on engine and options, so use the table above for your year.

Does the Toyota Camry need an AGM battery?

Our sources don't list AGM as required for the verified years. If the battery in your car says AGM on the label, replace it with another AGM.

How many cold cranking amps (CCA) does a Toyota Camry need?

Minimum ratings in our sources range from 585 to 605 CCA depending on year and engine. Buying a battery with the same or higher CCA in the correct group size is fine.

Why are some Camry years missing?

We only show years we could check against a manufacturer-grade source. Not shown yet: 2000-2006 (size depends on US vs. cold-climate build; sources split between 24F and 35), 2007-2009 2.4L (sources disagree), 2007-2017 hybrids (Japanese JIS sizes; Toyota says use the original battery's spec), 2025+ (new generation, not yet verified).
