Chevrolet Silverado 1500 battery size

Battery group size

H7

BCI 94R · LN4

2023 Chevrolet Silverado 1500 · 2 versions: see the table below

730 CCA minimum AGM required

All verified years: Group 78 (2000–2006) · Group H6 (48) (2008–2020) · Group H7 (94R) (2014–2020, 2023)

– = not specified in our sources (hover for details): match the CCA or type on the battery in your car now. Last verified 2026-10-19; sources are listed below.

Check your car first

• 2023 5.3L V8: GM's own 2023 chart confirms AGM and 730 CCA; group size from Interstate.
• 2023 6.2L V8: GM's own 2023 chart confirms AGM and 730 CCA; group size from Interstate.
• 2019–2020 2.7L Turbo: Mopar's guide lists 720 CCA; Interstate lists 730. We show the higher figure.
• 2014–2019 5.3L and 6.2L V8, primary battery (2019 = 1500 LD): Some trucks also have a second (auxiliary) Group 48 battery.
• 2010–2013 6.0L V8 Hybrid, 12V battery: Both sources agree on Group 48 (H6). They list different CCA figures, so we don't show one.
• 2009–2013 4.3L V6, 4.8L, 5.3L and 6.2L V8, optional battery: Some trucks came with a higher-rated optional battery (same group size). If yours has one, replace like for like.
• 2000–2005 4.3L V6, 4.8L and 5.3L V8, optional battery: Some trucks came with a higher-rated optional battery (same group size). If yours has one, replace like for like.
• Some rows depend on trim or equipment (see the version column in the table). If you're not sure which applies, match the battery already in your car.
• Not shown yet: 2007 (old-body 'Classic' and new-body trucks were both sold as 2007 models, with different sizes), 2009 Hybrid (one source), 6.0L, 8.1L and diesel trucks (mostly HD models, not covered here), 2021-2022 (one source only), 3.0L Duramax diesel (one group-size source), 2023 2.7L and 2024+ (GM lists AGM and CCA but not group size).

Confirm in your owner's manual. Battery fitment can change with engine, trim, option packages, market (US vs. Canada) and mid-year production changes. Before you buy, check the label on the battery that's in your car now and your owner's manual.

Sources for each row

Full source list: 2021 Mopar Batteries Application Guide (BCI replacement data) (checked 2026-10-21) · Interstate Batteries Application Guide 2023 (2000-2023 model years) (checked 2026-10-21) · GM Original Equipment Battery Ratings, 2023 model year (checked 2026-10-19). We store facts and links only; we don't copy manuals or guides. How we check specs.

How to replace the battery

Tools: 10 mm wrench or socket (some hold-downs need 12 or 13 mm or an extension), gloves, eye protection, terminal brush. Time: about 15–30 minutes for an under-hood battery; longer if it's in the trunk or under a seat.

1. Park, turn everything off and take the key or fob out of the car.
2. Disconnect the negative (–) cable first, then the positive (+).
3. Remove the hold-down and lift the battery out. Batteries are heavy (often 35–60 lb); lift with your legs.
4. Clean the tray and cable ends. Set in the new battery with the posts on the same sides as the old one.
5. Fit the hold-down, connect positive (+) first, then negative (–). Tighten until the clamps don't twist by hand.
6. If your car has a vent tube on the battery (common for trunk or cabin batteries), reconnect it.
7. Start the car. Some newer vehicles with a battery monitor need a reset or registration after a new battery. Your owner's manual explains it; a parts store or dealer can do it if needed.

Most parts stores take old batteries for recycling and usually refund a core charge.

Recalls for the Chevrolet Silverado 1500 (2000–2023)

NHTSA lists 47 recall campaigns across the years shown on this page (all components, not just batteries). Check your own car by VIN at nhtsa.gov/recalls.

Most recent 6 shown. Source: NHTSA Recalls API (recallsByVehicle), snapshot 2026-10-21.

FAQ

What size battery does a Chevrolet Silverado 1500 take?

Verified sizes by year: Group 78 (2000–2006), Group H6 (48) (2008–2020), Group H7 (94R) (2014–2020, 2023). The exact size depends on engine and options, so use the table above for your year.

Does the Chevrolet Silverado 1500 need an AGM battery?

Our sources list an AGM battery for: 2023 5.3L V8; 2023 6.2L V8; 2019–2020 2.7L Turbo; 2019–2020 5.3L V8 (VIN code D); 2019–2020 6.2L V8 (primary battery). If your car came with an AGM or EFB battery, replace it with the same type.

How many cold cranking amps (CCA) does a Chevrolet Silverado 1500 need?

Minimum ratings in our sources range from 600 to 770 CCA depending on year and engine. Buying a battery with the same or higher CCA in the correct group size is fine.

Why are some Silverado 1500 years missing?

We only show years we could check against a manufacturer-grade source. Not shown yet: 2007 (old-body 'Classic' and new-body trucks were both sold as 2007 models, with different sizes), 2009 Hybrid (one source), 6.0L, 8.1L and diesel trucks (mostly HD models, not covered here), 2021-2022 (one source only), 3.0L Duramax diesel (one group-size source), 2023 2.7L and 2024+ (GM lists AGM and CCA but not group size).
